Features

• Weighing slip printer
• Large battery for long battery life
• OLED display for easy setup
• Print anytime, anywhere
• Anti-collision design for drop resistance
• Compact size for portability
• Print Method: Direct Thermal
• Resolution: 203 DPI
• Printing Width: 104mm
• Interface: USB+Bluetooth / USB+WIFI
• Print Speed: 101mm (4") / s

Memory

• RAM: 8M
• FLASH: 16M

Built-in Fonts

• Common single-byte fonts: FONT 0 to FONT 8
• Simplified Chinese (GB18030): 16×16, 20×20
• Traditional Chinese (BIG5): 24×24
• Korean (full text)
• Windows fonts (*.ttf) can be downloaded via software

Barcode Character Graphics

• 1D Barcode :Code 39, Code 93, Code 128UCC,
  Code 128 subsets A, B, C, Codabar,
  Interleaved 2 of 5, EAN-8, EAN-13,
  EAN-128, UPC-A, UPC-E,
  EAN and UPC 2(5) digits add-on
• 2D Barcode: PDF-417, DataMatrix, QR code
• Rotation: 0°, 90°, 180°, 270°
• Graphics: Printing of monochrome PCX, BMP and other image files

Sensors

• Gap sensor
• Cover opening sensor
• Black mark sensor

Power Supply

• Battery: 7.4V rechargeable Li-ion battery, 3000mAh
• Input: AC 100V–240V 50/60Hz
• Output: DC 5V/1A

Paper

• Paper Type: Thermal Receipt Paper
• Paper Width: 30mm ~ 110mm
• Paper Thickness: 0.06 ~ 0.2mm
• Roll Diameter: Max. Ø56 mm
• Paper Load: Easy paper loading
• Paper Cut: Manual tear

Physical Characteristics

• Working Condition: -20°C ~ 52°C, 10% ~ 85% RH, no-condensing
• Storage Condition: -20°C ~ 60°C, 5% ~ 90% RH, no-condensing
• Dimensions: 155(D) × 132(W) × 71(H) mm
• Weight: Net 0.47kg / Gross 0.76kg

Reliability

• Printing head: 50km

Accessories

• USB data cable
• Charging head
• Instruction manual
• Battery

Packing

• Individual box: 210 × 136 × 76 mm (1 unit/carton)
• Master carton: 460 × 290 × 420 mm (20 units/carton)

OS / Compatibility

• Emulation: TSPL, ZPL, CPCL, ESC/POS (Default AUTO)
• Driver: Windows / Mac / Linux
• SDK: Android / iOS / Windows
